Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 437 407 367 360
Stack 649 585 501 723
Top Tube (effective) 548 551 543 612
Seat Tube C-T 459 487 557 481
Head Angle 56 68 65 75
Seat Angle 86 63 80 60
Head Tube 136 123 179 214
Chainstay 406 442 421 364
Wheelbase 1216 1054 1085 1240
Front Centre 536 542 611 680
BB Drop 79 72 85 77
Fork Length (A2C) 314 412 317 415
Rider Height 157-171 168-180 176-186 183-195
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
