Geometry

  X Small Small Medium Large X-Large
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 305 310 338 349 344
Stack 625 528 538 482 495
Top Tube (effective) 510 505 525 558 504
Seat Tube C-T 411 604 549 476 706
Head Angle 69 69 82 78 80
Seat Angle 69 73 59 78 69
Head Tube 104 161 185 208 235
Chainstay 401 410 427 475 399
Wheelbase 840 913 1067 1020 1112
Standover 636 820 895 970 1001
BB Drop 52 69 56 50 48
Seatpost Diameter 25 29 27 25 23
Data Source 8bar 8bar 8bar 8bar 8bar

Measurements are in millimeters and degrees.
