Geometry

  S
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 430
Stack 553
Top Tube (effective) 559
Seat Tube C-T 488
Seat Tube C-C 452
Head Angle 63
Seat Angle 73
Head Tube 107
Chainstay 444
Wheelbase 1067
Front Centre 632
Standover 850
BB Drop 53
BB Height 257
Fork Rake / Offset 48
Data Source Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
