Geometry

  XXS XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 365 319 406 402 412 334
Stack 526 523 433 459 538 583
Top Tube (effective) 438 439 567 522 651 522
Seat Tube C-T 538 564 502 479 484 667
Seat Angle 60 65 58 81 83 58
Head Tube 98 143 158 123 196 185
Chainstay 382 331 469 383 473 394
Wheelbase 792 948 852 1129 954 1083
Rider Height 153-159 160-167 168-173 174-179 180-185 186-192
Bike Weight >5.75
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
