Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 382 423 312 420
Stack 561 623 702 593
Top Tube (effective) 563 609 596 486
Seat Tube C-T 430 438 572 496
Head Angle 85 68 76 80
Seat Angle 66 84 79 69
Head Tube 135 151 186 249
Chainstay 442 488 443 331
Wheelbase 983 1005 1102 1020
BB Drop 79 64 67 75
Fork Rake / Offset 52 38 52 45
Fork Length (A2C) 405 374 409 398
Axle Spacing 127 120 128 107
Rider Height 168 – 175CM 175 – 180CM 180 – 185CM 185 – 193CM
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
