Geometry

  S (27.5/High) S (29/Low) M (27.5/High) M (29/Low) L (29/Low) L (27.5/High)
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 489 467 415 470 515 526
Stack 517 656 630 725 766 748
Top Tube (effective) 501 662 543 528 517 689
Seat Tube C-T 382 326 381 332 524 460
Head Angle 62 69 66 59 68 68
Seat Angle 87 69 71 83 85 83
Head Tube 90 118 127 109 147 110
Chainstay 502 438 370 522 485 509
Wheelbase 1363 1382 1421 1108 1396 1249
BB Drop 31 31 40 45 43 32
BB Type BSA 73 BSA 73 BSA 73 BSA 73 BSA 73 BSA 73
Fork Rake / Offset 42 52 46 43 43 48
Fork Length (A2C) 669 627 595 512 543 511
Seatpost Diameter 27 33 33 25 29 36
Axle Spacing 148x12 148x12 148x12 148x12 148x12 148x12
Wheel Size MX 27 MX 30 33 MX
Crank Length 184 146 159 178 154 156
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
