Geometry

  M XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Top Tube (effective) 611 559
Seat Tube C-T 447 608
Head Angle 61 67
Seat Angle 73 58
Head Tube 147-171 195-219
Chainstay 359 354
Wheelbase 821 878
Standover 664 692
BB Drop 61 59
Data Source Manufacturer Manufacturer

Note: 3D Head Tube allows adjustment from 195mm to 219mm

Measurements are in millimeters and degrees.
