Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 494 497 457 474
Stack 609 606 501 666
Top Tube (effective) 490 563 613 613
Seat Tube C-C 331 389 477 482
Head Angle 75 76 77 66
Seat Angle 89 73 69 79
Head Tube 113 108 101 150
Chainstay 445 444 462 452
Wheelbase 961 997 1178 1272
Standover 667 851 631 725
BB Drop 28 35 30 36
BB Height 355 394 378 279
Fork Rake / Offset 42 48 41 39
Fork Length (A2C) 523 635 518 519
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
