Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 441 511 432 593
Stack 616 491 570 685
Top Tube (effective) 478 512 696 519
Seat Tube C-T 443 389 442 471
Head Angle 60 59 60 53
Seat Angle 70 70 65 72
Head Tube 111 82 134 117
Chainstay 457 484 514 478
Wheelbase 1082 1272 1446 1140
Standover 756 637 635 710
BB Drop 28 29 33 31
BB Height 377 384 382 411
Fork Rake / Offset 35 35 44 43
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
