Geometry

  M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 355 323 387
Stack 494 707 685
Top Tube (effective) 498 576 624
Seat Tube C-T 537 629 655
Head Angle 64 61 61
Seat Angle 65 73 61
Head Tube 150 168 247
Chainstay 392 389 443
Wheelbase 1278 1133 1273
BB Drop 85 72 71
Data Source Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
