Geometry

  XS S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 414 372 370 436 322 481
Stack 534 515 591 633 690 694
Top Tube (effective) 454 575 447 570 536 661
Seat Tube C-T 331 510 469 507 644 627
Seat Tube C-C 457 427 576 585 558 670
Head Angle 68 81 74 77 73 76
Seat Angle 61 80 88 78 81 75
Head Tube 108 151 168 135 158 178
Chainstay 402 378 502 456 463 412
Wheelbase 1017 871 1021 1024 1230 955
Front Centre 649 554 698 656 672 674
Standover 870 619 745 683 993 840
BB Drop 284 245 261 263 238 265
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
