Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 461 440 340 367
Stack 715 555 557 681
Top Tube (effective) 622 715 570 671
Seat Tube C-T 399 544 638 506
Head Angle 57 72 63 67
Seat Angle 66 68 81 85
Head Tube 152 157 175 194
Chainstay 514 405 533 454
Wheelbase 1366 1044 1115 1301
Standover 437 351 389 360
BB Drop 78 69 67 81
Fork Rake / Offset 45 46 34 40
Fork Length (A2C) 381 542 467 483
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
