Geometry

  S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 427 449 486 380 392
Stack 495 529 543 517 750
Top Tube (effective) 607 594 575 708 686
Top Tube (actual) 459 573 503 497 581
Seat Tube C-T 366 420 451 508 612
Head Angle 70 73 73 56 69
Seat Angle 69 80 64 63 81
Head Tube 87 88 132 126 117
Chainstay 420 470 460 443 398
Wheelbase 1158 1275 870 1028 1298
Standover 793 674 700 834 802
BB Drop 69 59 70 83 79
Seatpost Diameter 32 25 29 28 31
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
