Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 360 309 374 376 404
Stack 567 578 461 453 653
Top Tube (effective) 572 463 533 568 546
Seat Tube C-C 473 555 528 501 600
Head Angle 86 76 72 60 60
Seat Angle 85 70 82 59 59
Head Tube 148 144 136 158 224
Chainstay 363 339 450 369 449
Wheelbase 1123 816 1101 1006 1203
BB Drop 78 79 70 73 57
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
