Geometry

  XS SM MD LA XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 387 457 486 452 514
Stack 553 512 559 579 562
Top Tube (effective) 568 526 700 681 672
Seat Tube C-T 329 395 468 435 460
Head Angle 66 74 74 81 80
Seat Angle 64 65 87 59 64
Head Tube 84 115 95 117 134
Chainstay 470 398 432 400 404
Wheelbase 1133 1087 959 1076 1334
Front Centre 636,7 754 590 747 612
BB Drop 57 57 48 51 67
Fork Length (A2C) 416 471 502 464 410
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
