Geometry

  SM MD LA
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 366 332 330
Stack 575 608 631
Top Tube (effective) 467 586 535
Seat Tube C-T 642 530 631
Head Angle 65 59 64
Seat Angle 82 60 85
Head Tube 108 110 101
Chainstay 330 458 372
Wheelbase 1067 1036 885
Front Centre 571 581 542
BB Drop 83 72 67
BB Height 261 305 247
Fork Length (A2C) 409 399 373
Wheel Size 573 567 629
HB Reach 21 71 434
Data Source Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
