Geometry

  SM MD LA XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 343 488 401 573
Stack 480 524 682 706
Top Tube (effective) 525 513 511 717
Seat Tube C-T 444 359 456 442
Head Angle 77 76 54 69
Seat Angle 75 89 88 82
Head Tube 103 76 90 140
Chainstay 433 340 445 382
Wheelbase 1221 1138 1157 1141
BB Drop 42 52 49 50
Seatpost Diameter 26 26 30 26
Tyre Max Width 2 2 2 2
Front Travel 104 100 121 95
Rear Travel 84 91 70 74
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
