Geometry

  XS S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 356 419 396 364 394 442
Stack 584 610 590 593 503 604
Top Tube (effective) 493 575 560 639 672 705
Seat Tube C-T 430 442 496 554 561 630
Head Angle 67 81 79 64 63 84
Seat Angle 77 72 64 83 67 84
Head Tube 138 152 159 141 200 231
Chainstay 439 423 358 445 442 422
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
