Geometry

  470 500 530 550 570 590 610
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 443 458 399 402 445 430 412
Stack 401 600 482 463 585 475 617
Top Tube (effective) 587 456 574 464 662 496 522
Top Tube (actual) 554 569 441 629 552 587 508
Seat Tube C-T 452 526 509 546 459 491 560
Seat Tube C-C 451 425 400 443 577 507 596
Head Angle 70.5° 71.5° 72° 72.5° 73° 73° 73.5°
Seat Angle 74.5° 74.5° 74° 73.5° 73.5° 73° 72.5°
Head Tube 116 103 146 157 151 191 208
Chainstay 335 431 349 351 473 348 388
BB Drop 49 62 61 63 64 68 60
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Measurements are in millimeters and degrees.
