Geometry

  47 51 54 56 58 61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 401 388 453 390 394 464
Stack 609 495 580 511 643 676
Top Tube (effective) 574 582 438 584 574 490
Seat Tube C-T 338 413 578 416 538 594
Head Angle 82 68 71 79 82 79
Seat Angle 73 77 71 79 86 84
Head Tube 98 133 128 186 239 258
Chainstay 388 468 444 411 479 455
Wheelbase 993 890 971 842 993 1053
Front Centre 543 485 579 687 632 588
Standover 609 726 848 739 842 924
BB Drop 61 66 83 66 60 74
Fork Rake / Offset 56 42 40 43 43 38
Trail 60 60 70 69 66 66
Fork Length (A2C) 328 328 419 395 353 381
Seatpost Length 327 290 291 300 341 422
Seatpost Offset 13 17 12 12 16 15
Handlebar Width 390 - 438 390 - 438 390 - 438 410 - 458 410 - 458 430 - 478
Stem Length 100 82 100 90 131 88
Stem Angle -6 -7 -8 -8 -8 -8
Crank Length 191 175 199 171 140 179
Rider Height <160 158-174 172-180 178-186 184-192 >190
HB Drop 141 120 142 135 136 139
HB Reach 56 77 72 82 74 68
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
