Geometry

  48 51 54 57 60
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 306 451 395 355 451
Stack 477 581 482 569 643
Top Tube (effective) 601 432 636 493 646
Seat Tube C-T 512 408 390 494 587
Head Angle 82 59 66 70 72
Seat Angle 71 69 63 79 62
Head Tube 100 134 145 149 245
BB Drop 72 70 60 64 73
Handlebar Width 360 362 383 490 433
Crank Length 166 143 188 198 165
Rider Height < 164 164 - 172 170 - 180 178 - 188 > 188
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Measurements are in millimeters and degrees.
