Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 440 421 465 399 553
Stack 693 713 670 522 578
Top Tube (effective) 598 581 615 752 694
Seat Tube C-T 337 499 459 519 527
Head Angle 67 80 76 70 61
Seat Angle 70 60 83 70 86
Head Tube 97 106 115 94 118
Chainstay 501 478 475 414 482
BB Type 73mm threaded 73mm threaded 73mm threaded 73mm threaded 73mm threaded
Seatpost Diameter 31.6mm 31.6mm 31.6mm 31.6mm 31.6mm
Axle Spacing 100/142 100/142 100/142 100/142 100/142
Wheel Size 29" 29" 29" 29" 29"
Front Travel 129 109 112 153 126
Rear Travel 144 121 121 120 144
Data Source Retailer Retailer Retailer Retailer Retailer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
