Geometry

  47 51 54 56 58 61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 364 444 430 434 370 354
Stack 576 555 456 609 507 636
Top Tube (effective) 485 588 571 638 641 630
Seat Tube C-T 459 438 579 628 563 627
Head Angle 78 75 73 64 72 65
Seat Angle 87 72 72 70 61 65
Head Tube 132 108 130 144 184 231
Chainstay 366 435 351 360 458 461
Wheelbase 788 808 863 968 941 1025
Front Centre 652 608 547 491 564 507
Standover 864 719 739 745 775 684
BB Drop 74 71 58 55 56 80
Fork Rake / Offset 49 39 36 49 43 35
Trail 71 53 62 59 55 52
Fork Length (A2C) 409 398 336 425 395 318
Seatpost Length 264 291 368 333 351 335
Seatpost Offset 17 16 17 12 12 15
Handlebar Width 321 484 357 419 388 381
Stem Length 76 119 107 113 110 123
Stem Angle +/- 8 +/- 8 +/- 8 +/- 8 +/- 8 +/- 8
Crank Length 188 202 175 163 171 205
HB Drop 118 111 140 101 122 130
HB Reach 86 84 72 81 78 70
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Note: Not sure

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
