Geometry

  48 51 54 56 58 61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 441 378 445 317 320 444
Stack 463 611 557 617 494 630
Top Tube (effective) 463 523 474 515 666 638
Seat Tube C-C 574 553 633 618 666 627
Head Angle 61 76 78 73 73 70
Seat Angle 84 60 87 87 68 88
Head Tube 104 122 164 130 203 227
Chainstay 467 353 324 411 347 343
Wheelbase 1089 956 1000 985 1164 1006
Front Centre 497 596 697 511 702 596
BB Drop 74 69 70 63 76 80
Fork Rake / Offset 37 45 35 48 38 37
Trail 60 62 62 70 68 57
Fork Length (A2C) 322 308 310 401 416 415
Tyre Max Width 373 485 362 397 525 396
Seatpost Length 220 168 255 204 208 297
Seatpost Offset 0 - 15 - 30 0 - 15 - 30 0 - 15 - 30 0 - 15 - 30 0 - 15 - 30 0 - 15 - 30
Stem Length 75 107 117 99 133 140
Stem Angle +/- 6 +/- 6 +/- 6 +/- 6 +/- 6 +/- 6
Crank Length 190 190 188 174 167 159
Rider Height <170 168-178 175-183 180-188 185-193 >190
HB Drop 135 128 103 132 145 98
HB Reach 78 73 91 80 88 72
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
