Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 481 388 546 457
Stack 683 715 598 537
Top Tube (effective) 485 621 607 720
Seat Tube C-T 405 402 508 591
Head Angle 62 67 62 69
Seat Angle 76 79 79 65
Head Tube 104 75 85 131
Chainstay 342 418 478 433
Wheelbase 1286 1185 1203 1198
BB Drop 65 63 56 57
Fork Rake / Offset 36 41 40 51
Fork Length (A2C) 420 521 434 447
Wheel Size 26 33 25 27
Seatpost Length 336 467 472 360
Handlebar Width 847 887 698 817
Stem Length 68 50 70 82
Stem Angle ±5 ±5 ±5 ±5
Crank Length 180 152 184 181
Front Travel 106 119 109 105
Rear Travel 0 0 0 0
Rider Height <170 170-182 180-192 >190
HB Reach 4 3 4 3
Front Mech 638 646 614 686
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
