Geometry

  S M L
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 350 434 478
Stack 651 599 731
Top Tube (effective) 508 663 705
Seat Tube C-T 399 420 522
Head Angle 75 76 81
Seat Angle 68 81 73
Head Tube 101 118 134
Chainstay 352 448 395
Wheelbase 1108 930 1284
BB Drop 64 57 55
Fork Rake / Offset 43 42 53
Seatpost Length 50 70 58
Handlebar Width 582 823 820
Data Source Manufacturer Manufacturer Manufacturer

Note: Stack / reach as quoted on site but may be wrong way around

Measurements are in millimeters and degrees.
