Geometry

  44 48 51 54 57 60
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 374 312 421 367 458 381
Stack 593 535 628 577 556 649
Top Tube (effective) 469 600 549 626 645 694
Top Tube (actual) 521 421 485 479 467 683
Seat Tube C-T 480 384 582 621 652 668
Head Angle 69 79 76 82 76 71
Seat Angle 62 84 61 66 64 76
Head Tube 141 127 145 174 174 189
Chainstay 471 459 380 372 467 485
Data Source Bottecchia Bottecchia Bottecchia Bottecchia Bottecchia Bottecchia

Measurements are in millimeters and degrees.
