Geometry

  50 52 54 56 58
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 308 400 370 353 438
Stack 478 538 529 479 483
Top Tube (effective) 468 616 632 577 507
Seat Tube C-T 473 616 621 663 675
Head Angle 74 66 81 68 73
Seat Angle 75 78 70 76 77
Head Tube 116 116 125 144 221
Chainstay 485 498 364 398 408
BB Drop 84 72 70 86 87
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
