Geometry

  P M G GG
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 443 346 365 443
Stack 687 518 567 569
Top Tube (effective) 515 452 631 602
Top Tube (actual) 509 510 669 614
Seat Tube C-T 425 594 515 506
Head Angle 76 63 75 61
Seat Angle 79 58 69 71
Head Tube 116 161 152 185
Chainstay 476 439 417 455
Wheelbase 1178 909 1133 975
Front Centre 561 713 770 626
Standover 746 896 805 1024
BB Drop 83 85 86 72
BB Height 337 301 313 240
Fork Rake / Offset 45 43 57 48
Trail 79 69 64 89
Handlebar Width 494 361 430 446
Crank Length 181 199 157 173
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
