| 3XS | 2XS | XS | S | M | L | XL | 2XL | |
|---|---|---|---|---|---|---|---|---|
| Add to Compare | ||||||||
| Reach | 416 | 392 | 443 | 315 | 373 | 335 | 483 | 473 |
| Stack | 498 | 441 | 538 | 548 | 635 | 507 | 558 | 634 |
| Top Tube (effective) | 531 | 498 | 561 | 591 | 489 | 524 | 684 | 542 |
| Seat Tube C-T | 429 | 516 | 434 | 548 | 485 | 619 | 620 | 560 |
| Head Angle | 72 | 84 | 77 | 77 | 61 | 71 | 63 | 70 |
| Seat Angle | 68 | 85 | 64 | 82 | 66 | 70 | 67 | 72 |
| Head Tube | 110 | 161 | 128 | 141 | 186 | 207 | 170 | 194 |
| Chainstay | 360 | 415 | 485 | 375 | 492 | 391 | 491 | 369 |
| Wheelbase | 1047 | 1002 | 1150 | 835 | 1119 | 969 | 894 | 863 |
| Standover | 558 | 644 | 737 | 866 | 680 | 840 | 815 | 1004 |
| BB Drop | 62 | 70 | 67 | 73 | 86 | 84 | 75 | 78 |
| BB Type | BB86 | BB86 | BB86 | BB86 | BB86 | BB86 | BB86 | BB86 |
| Seatpost Diameter | 22 | 25 | 23 | 28 | 28 | 26 | 24 | 27 |
| Wheel Size | 23 | 24 | 32 | 30 | 27 | 25 | 23 | 25 |
| Tyre Max Width | 29 | 40 | 35 | 28 | 36 | 34 | 29 | 32 |
| Seatpost Length | 311 | 302 | 286 | 314 | 359 | 291 | 310 | 383 |
| Max Post Insertion | 243 | 205 | 227 | 225 | 182 | 181 | 178 | 231 |
| Handlebar Width | 429 | 450 | 379 | 472 | 393 | 401 | 505 | 445 |
| Stem Length | 79 | 83 | 91 | 79 | 104 | 129 | 128 | 105 |
| Stem Angle | - 6⁰ | - 6⁰ | - 6⁰ | - 6⁰ | - 6⁰ | - 6⁰ | - 6⁰ | - 6⁰ |
| Crank Length | 145 | 145 | 171 | 185 | 139 | 164 | 179 | 196 |
| Rider Height | <158 | 158-164 | 164-170 | 170-177 | 177-184 | 184-191 | 191-197 | >197 |
| HB Drop | 121 | 106 | 142 | 153 | 125 | 137 | 138 | 104 |
| HB Reach | 66 | 56 | 72 | 56 | 75 | 56 | 75 | 61 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
