Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 347 382 375 520 533
Stack 564 482 522 506 522
Top Tube (effective) 581 655 676 555 537
Seat Tube C-T 420 385 498 474 393
Head Angle 78 60 77 58 63
Seat Angle 64 87 73 87 63
Head Tube 79 101 119 108 154
Chainstay 390 419 454 348 386
Wheelbase 1105 1129 1039 1054 1089
Standover 703 634 627 835 784
BB Drop 31 36 40 33 35
Seatpost Length 618 - 763 648 - 843 673 - 868 703 - 898 733 - 928
Rider Height ≤ 166 166 - 175 175 - 183 183 - 192 ≥ 192
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
