Geometry

  XS S M L XL
Add to Compare
Reach 458 450 450 438 498
Stack 537 693 563 741 524
Top Tube (effective) 451 486 661 512 559
Seat Tube C-T 399 348 381 538 539
Head Angle 64 69 54 71 77
Seat Angle 72 70 85 83 76
Head Tube 104 85 136 148 140
Chainstay 418 496 381 429 481
Wheelbase 1079 1092 1139 1290 1082
Standover 710 751 909 824 828
BB Drop 23 29 19 19 26
Seatpost Diameter 34 29 30 35 25
Axle Spacing 4 4 10 13 18
Wheel Size 27,5" 27,5" 27,5" 27,5" 27,5"
Seatpost Length 431 363 468 435 475
Max Post Insertion 198 218 225 313 250
Seatpost Offset 112 116 166 132 161
Handlebar Width 687 745 828 787 738
Stem Length 46 40 45 51 54
Crank Length 167 132 170 167 201
Front Travel 170 150 178 169 175
Rear Travel 132 122 125 164 152
Rider Height 165cm 170cm 178cm 186cm 186cm
Saddle Height 686 857 872 950 793
Data Source

Measurements are in millimeters and degrees.
