Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 303 449 365 428 460
Stack 520 593 490 471 606
Top Tube (effective) 425 528 508 455 632
Seat Tube C-T 469 498 518 483 615
Head Angle 69 75 66 83 68
Seat Angle 88 79 62 64 59
Head Tube 92 111 136 140 166
Chainstay 381 343 477 362 376
Wheelbase 799 883 998 1162 1203
Front Centre 605 674 579 489 620
BB Drop 62 67 73 68 57
Fork Rake / Offset 45 51 39 51 45
Trail 67 63 51 50 57
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
