Geometry

  XS S M L
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 444 371 406 466
Stack 494 423 553 446
Top Tube (effective) 436 480 510 625
Seat Tube C-T 491 436 417 595
Head Angle 71,5 71,5 58 62
Seat Angle 74 77 74,5 73,5
Head Tube 103 121 129 153
Wheelbase 1117 812 900 932
Front Centre 568,3 534 586,8 597,6
Standover 755 814 789 787
BB Drop 63 80 62 73
BB Type BB386EVO BB386EVO BB386EVO BB386EVO
Fork Rake / Offset 45 36 47 38
Tyre Max Width 27 27 29 24
Seatpost Offset 0 0 0 0
Stem Length 101 96 116 105
Frame Weight 938
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
