Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 420 378 419 383 432
Stack 481 653 612 542 616
Top Tube (effective) 521 542 515 612 535
Seat Tube C-T 505 569 425 433 543
Head Angle 77 57 61 77 73
Seat Angle 85 87 59 78 85
Head Tube 103 131 169 171 191
Chainstay 362 382 490 373 399
Wheelbase 850 835 919 837 1213
BB Drop 59 80 68 71 68
BB Type T47 T47 T47 T47 T47
Fork Rake / Offset 37 47 45 39 36
Fork Length (A2C) 332 334 419 457 435
Seatpost Diameter 28 28 24 21 23
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
