Geometry

  X-ShortTypical Rider Height: 137cm - 168cm ShortTypical Rider Height: 160cm - 178cm LongTypical Rider Height: 170cm - 188cm X-LongTypical Rider Height: 180cm - 198cm
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 385 407 495 541
Stack 513 662 458 682
Top Tube (effective) 584 565 587 599
Seat Tube C-T 323 248 293 355
Head Angle 62 67 67 76
Seat Angle 72 76 73 63
Head Tube 113 92 95 94
Chainstay 388 335 317 365
Wheelbase 1149 883 1229 917
Standover 496 551 540 574
BB Drop 31 26 29 31
BB Height 272 361 288 344
Wheel Size 26" 26" 26" 26"
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
