Geometry

  S M M/L L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 395 503 488 527 529
Stack 598 564 668 536 591
Top Tube (effective) 468 593 676 586 745
Seat Tube C-T 362 380 541 435 527
Head Angle 65° 65° 65° 65° 65°
Seat Angle 75° 75° 75° 75° 75°
Head Tube 106 107 106 83 112
Chainstay 469 434 439 397 491
Wheelbase 1178 988 1178 1300 1118
Standover 641 623 800 859 940
BB Height 368 370 369 273 287
BB Type bb92 (press fit) bb92 (press fit) bb92 (press fit) bb92 (press fit) bb92 (press fit)
Fork Rake / Offset 51 56 56 43 52
Seatpost Diameter 29 34 37 33 35
Front Travel 173 187 165 161 187
Rider Height 5'2"-5'7 5'5"-5'10 5'8"-6'2" 6'-6'4" 6'3"-6'7"
Headset 44-56 tapered 44-56 tapered 44-56 tapered 44-56 tapered 44-56 tapered
Seat Clamp 35 33 37 39 38
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
