Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 461 394 497 422
Stack 693 669 679 716
Top Tube (effective) 507 600 679 601
Seat Tube C-T 449 474 407 432
Head Angle 73 66 67 64
Seat Angle 65 75 81 83
Head Tube 117 113 131 139
Chainstay 398 382 359 452
Wheelbase 1279 1133 1038 1229
BB Drop 40 44 36 33
Fork Length (A2C) 580 492 541 563
Seatpost Diameter 34 25 32 32
Wheel Size 28 30 24 27
Front Travel 141 124 147 132
Rear Travel 152 150 142 115
Shock Size 210x50 210x50 210x50 210x50
Rider Height 151-170 168-180 178-190 188-210
Bike Weight 16 KG 16 KG 16 KG 16 KG
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
