Geometry

  S High S Low M High M Low L High L Low XL High XL Low
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 499 442 395 474 398 561 453 421
Stack 621 549 658 681 638 731 721 573
Top Tube (effective) 524 505 633 613 735 523 514 760
Seat Tube C-T 307 361 351 390 500 429 456 408
Head Angle 67 54 69 60 62 75 70 64
Seat Angle 67 75 64 70 86 76 74 81
Head Tube 132 142 136 149 145 153 126 115
Chainstay 487 375 349 369 490 489 406 442
Wheelbase 1232 1234 1243 1252 1128 1312 1251 1407
BB Drop 19 26 23 26 20 28 21 25
Fork Rake / Offset 48 42 44 41 35 46 48 50
Fork Length (A2C) 544 546 551 605 535 488 522 684
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
