Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 349 372 342 392
Stack 554 536 663 557
Top Tube (effective) 619 477 463 516
Seat Tube C-T 533 562 541 569
Seat Angle 71 88 82 80
Head Tube 63 67 71 62
Chainstay 424 412 463 414
Wheelbase 1081 973 1183 1145
Data Source Forum Post Forum Post Forum Post Forum Post

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
