| Small | Medium | Large | |
|---|---|---|---|
| Add to Compare | |||
| Reach | 420 mm | 440 mm | 465 mm |
| Top Tube (effective) | 571 mm | 591 mm | 616 mm |
| Seat Tube C-T | 380 mm | 420 mm | 460 mm |
| Head Angle | 61 | 75 | 58 |
| Seat Angle | 67 | 75 | 69 |
| Head Tube | 115 mm | 115 mm | 115 mm |
| Chainstay | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1200 mm | 1220 mm | 1245 mm |
| BB Drop | 9 | 12 | 12 |
| BB Type | BSA73 | BSA73 | BSA73 |
| Fork Rake / Offset | 43 | 44 | 43 |
| Fork Length (A2C) | 572 mm | 572 mm | 572 mm |
| Seatpost Diameter | 31.6 mm | 31.6 mm | 31.6 mm |
| Axle Spacing | 148x12 | 148x12 | 148x12 |
| Wheel Size | 27.5 / 29 | 27.5 / 29 | 27.5 / 29 |
| Tyre Max Width | 2.7 / 2.5 | 2.7 / 2.5 | 2.7 / 2.5 |
| Front Travel | 170 - 180 mm | 170 - 180 mm | 170 - 180 mm |
| Rear Travel | 170 - 180 mm | 170 - 180 mm | 170 - 180 mm |
| Shock Size | 230x65 / 240x76 | 230x65 / 240x76 | 230x65 / 240x76 |
| Rider Height | 150 - 165 cm | 165 - 180 cm | 180 - 190 cm |
| Headset | 44/55 mm | 44/55 mm | 44/55 mm |
| Seat Clamp | 34.9 mm | 34.9 mm | 34.9 mm |
| Frame Weight | 3.77 kg | 3.85 kg | 3.93 kg |
| Data Source | Seller | Seller | Seller |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
