Geometry

  50 cm 53 cm 56 cm 58 cm 60 cm 62 cm
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 404 449 338 373 377 391
Stack 444 628 657 652 536 582
Top Tube (effective) 533 440 482 671 640 482
Seat Tube C-C 457 479 412 568 537 525
Head Angle 80 74 76 59 86 77
Seat Angle 71 69 86 63 83 78
Head Tube 96 116 137 213 238 269
Chainstay 345 418 465 394 459 362
Wheelbase 845 997 1029 1004 1231 1205
Standover 796 622 874 867 833 872
BB Drop 82 71 70 58 64 66
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
