Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 403 410 384 378 381
Stack 457 623 566 557 744
Top Tube (effective) 494 635 505 485 532
Seat Tube C-C 345 466 502 514 644
Head Angle 57 82 75 61 74
Seat Angle 80 61 76 71 69
Head Tube 110 137 185 173 168
Chainstay 428 428 468 398 492
Wheelbase 914 862 892 969 904
BB Drop 65 70 69 67 78
Wheel Size 591 590 708 661 634
Tyre Max Width 56 51 41 51 53
Seatpost Length 307 344 367 401 428
Max Post Insertion 28 24 23 29 27
Handlebar Width 449 439 388 395 347
Stem Length 74 103 80 91 109
Stem Angle -5 -5 -5 -5 -6
Crank Length 181 134 179 180 176
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
