Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 317 402 334 422 402
Stack 473 551 478 668 687
Top Tube (effective) 544 623 510 685 698
Seat Tube C-C 439 412 414 440 502
Head Angle 64 57 69 72 67
Seat Angle 77 75 88 83 67
Head Tube 96 134 174 163 234
Chainstay 418 517 526 367 354
Wheelbase 857 1110 1188 1219 959
BB Drop 83 57 75 56 70
Seatpost Length 359 340 381 457 436
Handlebar Width 356 359 475 501 425
Stem Length 65 75 96 109 108
Crank Length 183 151 179 154 152
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
