Geometry

  XS S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 424 404 318 435 425 425
Stack 617 464 501 520 681 575
Top Tube (effective) 508 436 584 486 512 511
Seat Tube C-T 533 406 607 588 606 503
Head Angle 81 73 82 61 70 61
Seat Angle 64 77 65 59 82 83
Head Tube 108 152 167 217 165 190
Chainstay 408 441 410 484 397 477
Wheelbase 911 990 1059 1207 1192 1172
Standover 781 880 879 756 773 1016
BB Drop 79 59 79 60 68 80
BB Type Shimano BB-RS500PB, Pressfit Shimano BB-RS500PB, Pressfit Shimano BB-RS500PB, Pressfit Shimano BB-RS500PB, Pressfit Shimano BB-RS500PB, Pressfit Shimano BB-RS500PB, Pressfit
Fork Rake / Offset 44 42 51 40 40 52
Seatpost Diameter 31 24 27 21 31 27
Axle Spacing 12x100mm/12x142mm 12x100mm/12x142mm 12x100mm/12x142mm 12x100mm/12x142mm 12x100mm/12x142mm 12x100mm/12x142mm
Wheel Size 641 851 825 856 765 706
Tyre Max Width 40 40 37 38 50 40
Seatpost Length 301 406 296 357 432 431
Handlebar Width 332 436 431 382 463 377
Stem Length 95 87 88 102 90 108
Stem Angle 5 6 5 7 5 5
Crank Length 162 179 190 145 178 169
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
