Geometry

  XS S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 303 329 447 406 366 465
Stack 543 471 704 653 580 747
Top Tube (effective) 616 580 569 535 655 604
Seat Tube C-T 450 559 494 547 443 545
Head Angle 71 60 79 75 61 61
Seat Angle 61 65 85 76 62 87
Head Tube 120 151 171 197 215 190
Chainstay 361 393 442 384 372 353
Wheelbase 1024 1211 1191 967 891 1261
Front Centre 543 719 573 756 564 633
BB Drop 67 73 63 67 87 64
BB Height 250 229 265 264 282 228
Fork Rake / Offset 42 56 45 47 46 58
Fork Length (A2C) 462 328 466 436 400 428
Wheel Size 722 710 708 685 759 787
Handlebar Width 412 467 422 465 406 506
Stem Length 67 80 82 65 77 107
Crank Length 183 178 166 153 163 163
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements

Also! Search by Stack and Reach

You can now search the database by numbers.

Find bikes that match your geometry criteria.
