Geometry

  43 46 48 51 53 56
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 401 351 438 343 369 343
Stack 550 534 634 454 584 612
Top Tube (effective) 538 534 622 654 500 489
Head Angle 76 62 68 77 69 63
Seat Angle 61 70 86 71 61 58
Head Tube 98 111 108 166 169 224
Chainstay 470 431 470 379 382 463
Wheelbase 782 1082 980 1039 852 841
Front Centre 564 681 664 547 712 496
BB Drop 72 83 82 75 80 72
Fork Rake / Offset 54 38 34 42 43 40
Fork Length (A2C) 324 422 361 442 422 356
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
