Geometry

  16" 18" 20"
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 470 522 424
Stack 683 662 542
Top Tube (effective) 643 673 754
Seat Tube C-T 409 392 420
Head Angle 73 55 76
Seat Angle 63 74 64
Head Tube 126 102 109
Chainstay 533 487 514
Wheelbase 1267 1259 1384
BB Drop -13 -13 -14
Fork Rake / Offset 47 48 47
Data Source Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
