Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 395 549 566 440
Stack 627 702 686 651
Top Tube (effective) 608 549 548 780
Seat Tube C-T 422 379 372 445
Head Angle 73 71 52 77
Seat Angle 67 63 80 69
Head Tube 97 99 113 142
Chainstay 354 493 488 442
Wheelbase 999 1162 1222 1048
Standover 586 602 722 662
BB Drop 32 31 35 28
BB Height 309 275 361 381
Fork Rake / Offset 48 43 43 46
Seatpost Diameter 29 38 34 34
Max Post Insertion 293 298 315 401
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
