Geometry

  SM (Low) SM (High) MD (Low) MD (High) LG (Low) LG (High) XL (Low) XL (High)
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 431 499 400 391 543 555 493 420
Stack 557 667 735 554 547 576 569 764
Top Tube (effective) 497 484 589 685 632 716 611 569
Head Angle 74 66,5 77 66,5 65 66,5 69 66,5
Seat Angle 75.7° 76.2° 75.6° 76.1° 75.4° 75.9° 75.3° 75.8°
Head Tube 95mm 95mm 105mm 105mm 115mm 115mm 125mm 125mm
Chainstay 432mm 430mm 432mm 430mm 432mm 430mm 432mm 430mm
Wheelbase 1166mm 1167mm 720m 1191mm 1191mm 1215mm 1215mm 1242mm 1242mm
Standover 513 381 379 406 514 395 478 372
BB Height 339,5 324 339,5 343 339,5 338 339,5 406
Data Source Alternative specification site Alternative specification site Alternative specification site Alternative specification site Alternative specification site Alternative specification site Alternative specification site Alternative specification site

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
